• UL recognized component listing and CSA certification ensures the product is safe for use.
• Double-shielded bearings extend the service life of the motor.
• Automatic reset thermal protector (as noted) protects against overload.
• Moderate starting torque helps reduce fan stresses.

Nameplate Specifications

Phase	1
Output HP	1.0 Hp
Output KW	0.75 kW
Voltage	230/115 V
Speed	1725/1425 rpm
Service Factor	1.4
Frame	L56None
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60/50 Hz
Current	4.3/8.6//5.2/10.4 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Capacitor Run, Low Starting Torque, Single Or Dual Voltage
Starting Method	Across The Line
Poles	4
Rotation	Reversible Clockwise
Mounting	Removable Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	12.19 in
Frame Length	6.25 in
Shaft Diameter	0.625 in
Shaft Extension	1.94 in

General Specifications

UPC	786674057068
Weight	38.00 LB
Packaged Length	17.00 IN
Packaged Width	11.00 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
