• UL recognized component listing and CSA certification ensures the product is safe for use.
• Double-shielded bearings extend the service life of the motor.
• Automatic reset thermal protector (as noted) protects against overload.
• Moderate starting torque helps reduce fan stresses.

Nameplate Specifications

Phase	1
Output HP	.75/.33 Hp
Output KW	0.56 kW
Voltage	115 V
Speed	1725/1140 rpm
Service Factor	1
Frame	56
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Efficiency	72 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	8.6/6.1 A
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y
CE	Y
Number of Speeds	2

Technical Specifications

Electrical Type	Capacitor Start Induction Run
Starting Method	Across The Line
Poles	4/6
Rotation	Selective Counterclockwise
Mounting	Resilient Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	NEMA 56
Overall Length	11.97 in
Frame Length	7.65 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in

General Specifications

UPC	786674075246
Weight	34.00 LB
Packaged Length	16.00 IN
Packaged Width	8.00 IN
Packaged Height	10.00 IN
HTC	8501.40.4040
Country of Origin	Mexico
