• Resilient Base
• Single and two speed

Nameplate Specifications

Phase	1
Output HP	1.000 Hp
Output KW	0.75 kW
Voltage	208-230/115 V
Speed	1725 rpm
Service Factor	1.25
Frame	K56
Enclosure	Drip Proof
Thermal Protection	No Protection
Ambient Temperature	40 °C
Frequency	60 Hz
Current	6.2-6.3/12.6 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Induction Run, Single Or Dual Voltage
Starting Method	Across The Line
Poles	4
Rotation	Reversible Counterclockwise
Mounting	Cushion Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	11.50 in
Frame Length	5.50 in
Shaft Diameter	0.625 in
Shaft Extension	1.97 in

General Specifications

UPC	786674016171
Weight	31.00 LB
Packaged Length	16.00 IN
Packaged Width	8.00 IN
Packaged Height	10.00 IN
Country of Origin	Mexico
