• Automatic reset thermal protector

Nameplate Specifications

Phase	1
Output HP	1.0 Hp
Output KW	0.75 kW
Voltage	115/230 V
Speed	1725 rpm
Service Factor	1.25
Frame	L56Y
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	13.0/6.5 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Induction Run, Single Or Dual Voltage
Starting Method	Across The Line
Poles	4
Rotation	Reversible Clockwise
Mounting	Cushion Ring
Drive End Bearing	Sleeve
Opp Drive End Bearing	Sleeve
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	11.62 in
Frame Length	6.25 in
Shaft Diameter	0.625 in
Shaft Extension	1.37 in

General Specifications

UPC	786674015556
Weight	35.00 LB
Packaged Length	16.00 IN
Packaged Width	8.00 IN
Packaged Height	10.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
