• Single speed
• Capacitor included

Nameplate Specifications

Phase	1
Output HP	1/3 Hp
Output KW	0.25 kW
Voltage	115 V
Speed	850 rpm
Service Factor	1
Frame	Y56Z
Enclosure	Totally Enclosed Air Over
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	5.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor, Single Or Dual Voltage
Starting Method	Across The Line
Poles	8
Rotation	Reversible Counterclockwise
Mounting	Cushion Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Special Extension
Overall Length	55.00 in
Frame Length	6.13 in
Shaft Diameter	0.749 in
Shaft Extension	22.97 in

General Specifications

UPC	786674015044
Weight	53.00 LB
Packaged Length	59.00 IN
Packaged Width	9.06 IN
Packaged Height	7.75 IN
HTC	8501.40.4040
Country of Origin	Mexico
