• Resilient Base

Nameplate Specifications

Phase	1
Output HP	3/4 Hp
Output KW	0.56 kW
Voltage	208-230 V
Speed	1075 rpm
Service Factor	1
Frame	K56Y
Enclosure	Open Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	6.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor, Single Or Dual Voltage
Starting Method	Across The Line
Poles	6
Rotation	Counterclockwise
Mounting	Cushion Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Flat
Overall Length	24.70 in
Frame Length	5.50 in
Shaft Diameter	0.665 in
Shaft Extension	7.5 in

General Specifications

UPC	786674014962
Weight	37.00 LB
Packaged Length	28.00 IN
Packaged Width	12.00 IN
Packaged Height	10.00 IN
HTC	8501.40.4040
Country of Origin	Mexico
