• Replacement for Hoffinger (Doughboy/Lomart)
• Sealed Ball Bearings
• No Base
• Threaded Shaft
• Rotation: CW Pump End

Nameplate Specifications

Phase	1
Output HP	1.0 Hp
Output KW	0.75 kW
Voltage	115 V
Speed	3450 rpm
Service Factor	1
Frame	V48Y
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	9.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Split Phase, Induction Run, Single Or Dual Voltage
Poles	2
Rotation	Clockwise Pump End
Mounting	Thru Bolt
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	3/8 THREADS
Overall Length	10.22 in
Frame Length	6.25 in
Shaft Diameter	0.500 in
Shaft Extension	2.16 in

General Specifications

UPC	786674014566
Weight	16.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
