• Two Speed
• 12 & 3 O'clock Conduit Entries
• 3-1/2" Shaft Height
• 50°C Ambient
• Four Thru Bolts on a 5.146 Bolt Circle
• Flex 48 LASAR XL for Extra Low Running Amps with 48/56 Base Mounting
• Threaded Shaft
• Rigid Base
• Energy Efficient
• Meets California Energy Commission Appliance Regulations 2008

Nameplate Specifications

Phase	1
Output HP	4.0-.42 Hp
Output KW	3.0 kW
Voltage	208-230 V
Speed	3450/1725 rpm
Service Factor	1
Frame	Y48Y
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	50 °C
Frequency	60 Hz
Current	12.0/3.5 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	2-2-VT

Technical Specifications

Electrical Type	Permanent Split Capacitor, High Speed; Capacitor Start, Low Speed
Poles	2/4
Rotation	Counterclockwise Pump End
Mounting	Thru Bolt
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	3/8 Threaded
Overall Length	14.33 in
Frame Length	9.50 in
Shaft Diameter	0.500 in
Shaft Extension	2.36 in

General Specifications

UPC	786674014481
Weight	33.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
