• Two Speed
• 12 & 3 O'clock Conduit Entries
• 3-1/2" Shaft Height
• 40°C Ambient
• Four Thru Bolts on a 5.146 Bolt Circle
• Flex 48 LASAR Line Low Amp Start and Run with 48/56 Base Mounting
• 48/56 Base Mounting
• Threaded Shaft
• Rigid Base
• Energy Efficient

Nameplate Specifications

Phase	1
Output HP	1.0/.125 Hp
Output KW	0.75 kW
Voltage	115 V
Speed	3450/1725 rpm
Service Factor	1
Frame	48Y
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	10.8/2.8 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	2

Technical Specifications

Electrical Type	Cap Start Low Speed, Psc High Speed
Starting Method	Across The Line
Poles	2/4
Rotation	Counterclockwise Pump End
Mounting	Thru Bolt
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	3/8 Threaded
Overall Length	12.71 in
Frame Length	7.50 in
Shaft Diameter	0.500 in
Shaft Extension	2.375 in

General Specifications

UPC	786674057310
Weight	25.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
