• Two Speed
• 12 & 3 O'clock Conduit Entries
• 3-1/2" Shaft Height
• 40°C Ambient
• Four Thru Bolts on a 5.146 Bolt Circle
• Flex 48 LASAR Line Low Amp Start and Run
• 48/56 Base Mounting
• Threaded Shaft
• Rigid Base

Nameplate Specifications

Phase	1
Output HP	3/4 - .10 Hp
Output KW	0.56 kW
Voltage	115 V
Speed	3450/1725 rpm
Service Factor	1
Frame	R48Y
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	8.8/2.6 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	2-2-VT

Technical Specifications

Electrical Type	Split Phase, Induction Run, Multi-Speed
Starting Method	Across The Line
Poles	2/4
Rotation	Counterclockwise Pump End
Mounting	Thru Bolt
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	3/8 Threaded
Overall Length	12.08 in
Frame Length	7.25 in
Shaft Diameter	0.500 in
Shaft Extension	2.36 in

General Specifications

UPC	786674014399
Weight	23.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	9.50 IN
HTC	8501.40.4040
Country of Origin	Mexico
