• 12 & 3 O'clock Conduit Entries
• 3-1/2" Shaft Height
• 40°C Ambient
• Stainless Steel Shaft
• Four Thru Bolts on a 5.146 Bolt Circle
• 48/56 Base Mounting
• Sealed Ball Bearings
• UL 1081 Design
• Rigid Base
• Threaded Shaft

Nameplate Specifications

Phase	1
Output HP	1.5 Hp
Output KW	1.1 kW
Voltage	230/115 V
Speed	3450 rpm
Service Factor	1
Frame	48Y
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	8.0/16.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Induction Run, Single Or Dual Voltage
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Thru Bolt
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	3/8 Threaded
Overall Length	12.08 in
Frame Length	7.50 in
Shaft Diameter	0.500 in
Shaft Extension	2.375 in

General Specifications

UPC	786674056979
Weight	20.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	9.50 IN
HTC	8501.40.6040
Country of Origin	Mexico
