• Two Speed
• Sealed Ball Bearings
• 50°C Ambient
• Energy Efficient High and Low Speed
• Open Dripproof
• Permanent Split Capacitor on High Speed
• Cap Star/Cap Run Low Speed
• 303 Stainless Steel Shaft
• Threaded Shaft
• Meets California Energy Commission Appliance Regulations 2008

Nameplate Specifications

Phase	1
Output HP	2.0-.33 Hp
Output KW	1.5 kW
Voltage	230 V
Speed	3450/1725 rpm
Service Factor	1.1
Frame	Y56Y
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	SF 10.0/3.5 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	2-2-VT

Technical Specifications

Electrical Type	Permanent Split Capacitor, High Speed; Split Phase, Low Speed
Poles	2/4
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	1/2 Threaded
Overall Length	14.40 in
Frame Length	9.50 in
Shaft Diameter	0.625 in
Shaft Extension	0.9 in

General Specifications

UPC	786674013545
Weight	37.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
