• Sealed Ball Bearings
• Two Speed
• Energy Efficient
• Permanent Split Capacitor
• UL 1081 Design
• High Speed Switchless
• Low Speed Microswitch
• Threaded Shaft
• 303 Stainless Steel Shaft
• Meets California Energy Commission Appliance Regulations 2008

Nameplate Specifications

Phase	1
Output HP	1.5-.20 Hp
Output KW	1.1 kW
Voltage	115 V
Speed	3450/1725 rpm
Service Factor	1.1
Frame	P56J
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	50 °C
Frequency	60 Hz
Current	SF 14.6/4.4 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	2-2-VT

Technical Specifications

Electrical Type	Permanent Split Capacitor, High Speed; Split Phase, Low Speed
Poles	2/4
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	7/16 Thread
Overall Length	13.54 in
Frame Length	8.00 in
Shaft Diameter	0.625 in
Shaft Extension	2.57 in

General Specifications

UPC	786674013422
Weight	35.00 LB
Packaged Length	16.00 IN
Packaged Width	9.00 IN
Packaged Height	8.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
