• Sealed Ball Bearings
• 304 Bearing Shaft End
• Energy Efficient
• 303 Stainless Steel Shaft
• Threaded Shaft
• Switchless
• Permanent Split Capacitor
• Open Dripproof
• UL 1081 Design

Nameplate Specifications

Phase	1
Output HP	2.0 Hp
Output KW	1.5 kW
Voltage	208-230 V
Speed	3450 rpm
Service Factor	1.2
Frame	Y56J
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	50 °C
Frequency	60 Hz
Current	SF 10.4-9.6 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor, Single Or Dual Voltage
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	7/16 Threaded
Overall Length	14.15 in
Frame Length	8.50 in
Shaft Diameter	0.625 in
Shaft Extension	2.57 in

General Specifications

UPC	786674013095
Weight	40.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
