• Heavy gauge steel frame and base

Nameplate Specifications

Phase	1
Output HP	3/4 Hp
Output KW	0.56 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1
Frame	56
Enclosure	Totally Enclosed Fan Cooled
Thermal Protection	Automatic
Ambient Temperature	40 °C
Frequency	60 Hz
Current	9.6/4.8 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Induction Run, Single Or Dual Voltage
Starting Method	Across The Line
Poles	2
Rotation	Reversible Counterclockwise
Mounting	Resilient Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	12.61 in
Frame Length	5.50 in
Shaft Diameter	0.625 in
Shaft Extension	1.94 in

General Specifications

UPC	786674056290
Weight	29.00 LB
Packaged Length	17.00 IN
Packaged Width	11.00 IN
Packaged Height	11.00 IN
HTC	8501.40.4040
Country of Origin	Mexico
