• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Premium efficiency promotes improved reliability.
• Heavy-duty, rolled steel construction ensures motor durability.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.

Nameplate Specifications

Phase	1
Output HP	3/4 Hp
Output KW	0.56 kW
Voltage	208-230/115 V
Speed	3450 rpm
Service Factor	1.25
Frame	J56
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	4.7-4.6/9.2 A
Duty	Continuous
Insulation Class	A
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Induction Run, Single Or Dual Voltage
Starting Method	Across The Line
Poles	2
Rotation	Reversible Clockwise
Mounting	Cushion Base
Drive End Bearing	Sleeve
Opp Drive End Bearing	Sleeve
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	11.13 in
Frame Length	5.13 in
Shaft Diameter	0.625 in
Shaft Extension	1.97 in

General Specifications

UPC	786674012692
Weight	27.00 LB
Packaged Length	13.00 IN
Packaged Width	10.00 IN
Packaged Height	10.00 IN
HTC	8501.40.4040
Country of Origin	Mexico
