• Sealed Ball Bearings
• Rotation: CW Non-Reversible
• 40°C Ambient
• UL 1081 Design
• No Base & Rigid Base
• Booster Pump - Cleaner

Nameplate Specifications

Phase	1
Output HP	3/4 Hp
Output KW	0.56 kW
Voltage	230/115 V
Speed	3450 rpm
Service Factor	1.5
Frame	N56CZ
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	SF 6.4/12.8 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Induction Run, Single Or Dual Voltage
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Special/Non-Standard
Motor Orientation	Horizontal
Drive End Bearing	Ball Brg
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	1/2 THREADS
Overall Length	14.13 in
Frame Length	7.25 in
Shaft Diameter	0.665 in
Shaft Extension	3.82 in

General Specifications

UPC	786674012647
Weight	27.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
