• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Double sealed ball bearings mechanically locked on shaft end.
• Continuous duty cycle design allows maximum operation at the rated power specifications.
• Class F insulation(as noted) protects motor for a maximum temperature rating.

Nameplate Specifications

Phase	1
Output HP	1/2 Hp
Output KW	0.37 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1.60
Frame	F56J
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	SF 10.0/5.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N

Technical Specifications

Electrical Type	Capacitor Start, Induction Run, Single Or Dual Voltage
Starting Method	Across The Line
Poles	2
Rotation	Clockwise
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Threaded
Overall Length	11.30 in
Frame Length	5.75 in
Shaft Diameter	0.625 in
Shaft Extension	2.45 in

General Specifications

UPC	786674069641
Weight	20.00 LB
Packaged Length	16.00 IN
Packaged Width	8.00 IN
Packaged Height	10.00 IN
HTC	8501.40.4040
Country of Origin	Mexico
