• Epoxy painted and stainless ratings available for corrosion protection.
• Washguard® duty ensures motor is fit for high-pressure washdown applications.
• Sealed bearings shut out contaminants that lead to bearing failure.
• Three phase motors are inverter rated and able to withstand higher voltage spikes.

Nameplate Specifications

Phase	1
Output HP	1.0 Hp
Output KW	0.75 kW
Voltage	208-230 V
Speed	3450 rpm
Service Factor	1.00
Frame	L56HCZ
Enclosure	Totally Enclosed Non Ventilated
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	4.8-4.5 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor, Single Or Dual Voltage
Starting Method	Across The Line
Poles	2
Rotation	Clockwise
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	11.97 in
Frame Length	6.25 in
Shaft Diameter	0.625 in
Shaft Extension	1.94 in

General Specifications

UPC	786674012517
Weight	37.00 LB
Packaged Length	16.00 IN
Packaged Width	8.00 IN
Packaged Height	10.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
