• UL recognized component listing and CSA certification ensures the product is safe for use.
• High starting torque on start-up, to achieve a higher starting load required in air compressor applications.
• Capacitor start or capacitor run for low-amp, high-efficiency, as noted.
• Heavy-duty construction ensures motor durability.

Nameplate Specifications

Phase	1
Output HP	5.0 Hp
Output KW	3.7 kW
Voltage	208-230 V
Speed	3450 rpm
Service Factor	1.15
Frame	R56HZ
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	22.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	N
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Capacitor Run, Single Or Dual Voltage
Starting Method	Across The Line
Poles	2
Rotation	Clockwise
Mounting	Rigid Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	14.56 in
Frame Length	8.75 in
Shaft Diameter	0.875 in
Shaft Extension	2.31 in

General Specifications

UPC	786674012425
Weight	47.00 LB
Packaged Length	19.00 IN
Packaged Width	12.00 IN
Packaged Height	10.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
