• Two Speed
• Sealed Ball Bearings
• 50°C Ambient
• Energy Efficient High and Low Speed
• Open Dripproof
• Permanent Split Capacitor on High Speed
• Cap Star/Cap Run Low Speed
• 303 Stainless Steel Shaft
• Threaded Shaft
• Meets California Energy Commission Appliance Regulations 2008

Nameplate Specifications

Phase	1
Output HP	1.0/ .12 Hp
Output KW	0.75 kW
Voltage	230 V
Speed	3450/1725 rpm
Service Factor	1.65
Frame	Y56Y
Enclosure	Open Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	50 °C
Frequency	60 Hz
Current	SF 7.4/1.4 A
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y
Number of Speeds	2-2VT

Technical Specifications

Electrical Type	Psc Low Speed, Cap Start/Cap Run High Speed
Starting Method	Across The Line
Poles	2/4
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	1/2 Thread
Overall Length	13.40 in
Frame Length	9.00 in
Shaft Diameter	0.625 in
Shaft Extension	0.91 in

General Specifications

UPC	786674012340
Weight	34.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
