• Sealed Ball Bearings
• Two Speed
• Energy Efficient
• Permanent Split Capacitor
• UL 1081 Design
• High Speed Switchless
• Low Speed Microswitch
• Threaded Shaft
• 303 Stainless Steel Shaft
• Meets California Energy Commission Appliance Regulations 2008

Nameplate Specifications

Phase	1
Output HP	1.0/ .12 Hp
Output KW	0.75 kW
Voltage	230 V
Speed	3450/1725 rpm
Service Factor	1.4
Frame	Y56J
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	50 °C
Frequency	60 Hz
Current	SF 6.6/1.25 A
Duty	Continuous
Insulation Class	F
UL	Recognized
CSA	Y
Number of Speeds	2-2VT

Technical Specifications

Electrical Type	Psc Low Speed, Cap Start/Cap Run High Speed
Poles	2/4
Rotation	Clockwise
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball Brg
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	7/16 Threaded
Overall Length	13.05 in
Frame Length	7.75 in
Shaft Diameter	0.625 in
Shaft Extension	2.57 in

General Specifications

UPC	786674060174
Weight	32.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
