• Two Speed
• PSC on High Speed
• Cap Start/Cap Run on Low Speed
• Rigid Base
• 50°C Ambient
• Four Thru Bolts on a 5.812 Bolt Circle
• Open Dripproof

Nameplate Specifications

Phase	1
Output HP	4.0 SPL Hp
Output KW	3.0 kW
Voltage	230 V
Speed	3450 rpm
Service Factor	1
Frame	P56Y
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	50 °C
Frequency	60 Hz
Current	12.0 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor, Single Or Dual Voltage
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Thru Bolt
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	3/8 Threaded
Overall Length	12.62 in
Frame Length	8.00 in
Shaft Diameter	0.500 in
Shaft Extension	2.37 in

General Specifications

UPC	786674012159
Weight	22.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.6040
Country of Origin	China
