• 50°C Ambient
• 304 Bearing Shaft End
• Switchless
• UL 1081 Design
• Permanent Split Capacitor
• Open Dripproof
• Rigid Base
• Threaded Shaft
• 303 Stainless Steel Shaft

Nameplate Specifications

Phase	1
Output HP	1.5 Hp
Output KW	1.1 kW
Voltage	230/115 V
Speed	3450 rpm
Service Factor	1
Frame	Y56J
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	50 °C
Frequency	60 Hz
Current	7.2/14.4 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor, Single Or Dual Voltage
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	7/16 Threaded
Overall Length	13.91 in
Frame Length	7.38 in
Shaft Diameter	0.625 in
Shaft Extension	2.57 in

General Specifications

UPC	786674012074
Weight	25.00 LB
Packaged Length	15.98 IN
Packaged Width	9.13 IN
Packaged Height	9.01 IN
HTC	8501.40.6040
Country of Origin	Thailand
