• UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
• Premium efficiency promotes improved reliability.
• Heavy-duty, rolled steel construction ensures motor durability.
• Permanently lubricated, double-sealed bearings extend the lifetime of the motor.

Nameplate Specifications

Phase	1
Output HP	2.0 Hp
Output KW	1.5 kW
Voltage	115/230 V
Speed	3450 rpm
Service Factor	1.15
Frame	56
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Efficiency	82.9 %
Ambient Temperature	40 °C
Frequency	60 Hz
Current	17.8/8.9 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
CE	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Capacitor Start, Capacitor Run, Single Or Dual Voltage
Starting Method	Across The Line
Poles	2
Rotation	Reversible Counterclockwise
Mounting	Resilient Base
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	Keyed
Overall Length	12.69 in
Frame Length	6.25 in
Shaft Diameter	0.625 in
Shaft Extension	1.88 in

General Specifications

UPC	786674073433
Weight	38.00 LB
Packaged Length	16.00 IN
Packaged Width	8.00 IN
Packaged Height	10.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
