• 50°C Ambient
• 304 Bearing Shaft End
• Switchless
• UL 1081 Design
• Permanent Split Capacitor
• Open Dripproof
• Rigid Base
• Threaded Shaft
• 303 Stainless Steel Shaft
• Meets California Energy Commission Appliance Regulations 2008

Nameplate Specifications

Phase	1
Output HP	1/2 Hp
Output KW	0.37 kW
Voltage	230/115 V
Speed	3450 rpm
Service Factor	1.6
Frame	L56J
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	50 °C
Frequency	60 Hz
Current	SF 4.4/8.8 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor, Single Or Dual Voltage
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	7/16 Threaded
Overall Length	11.94 in
Frame Length	6.25 in
Shaft Diameter	0.625 in
Shaft Extension	2.57 in

General Specifications

UPC	786674011879
Weight	22.00 LB
Packaged Length	16.00 IN
Packaged Width	9.50 IN
Packaged Height	11.00 IN
HTC	8501.40.4040
Country of Origin	Mexico
