• Sealed Ball Bearings
• 40°C Ambient
• Open Dripproof
• UL 1081 Design
• Pentair Pac Fab Replacement

Nameplate Specifications

Phase	1
Output HP	5.0 Hp
Output KW	3.7 kW
Voltage	208-230 V
Speed	3450 rpm
Service Factor	1
Frame	Y56Y
Enclosure	Drip Proof
Thermal Protection	Thermally Protected
Ambient Temperature	40 °C
Frequency	60 Hz
Current	21.0-19.4 A
Duty	Continuous
Insulation Class	B
UL	Recognized
CSA	Y
Number of Speeds	1

Technical Specifications

Electrical Type	Permanent Split Capacitor, Single Or Dual Voltage
Poles	2
Rotation	Counterclockwise Pump End
Mounting	Round
Motor Orientation	Horizontal
Drive End Bearing	Ball
Opp Drive End Bearing	Ball
Frame Material	Rolled Steel
Shaft Type	1/2 Threaded
Overall Length	14.90 in
Frame Length	10.50 in
Shaft Diameter	0.625 in
Shaft Extension	0.9444 in

General Specifications

UPC	786674011794
Weight	48.00 LB
Packaged Length	19.50 IN
Packaged Width	11.50 IN
Packaged Height	12.00 IN
HTC	8501.40.6040
Country of Origin	Mexico
