• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Model Name	U2_Type2_BushingMaster
Outside Diameter (in)	8.375 in
Keyseat	1 1/4 x 5/8
Wrench Torque (in-lb)	1,680
Bushing Type	U2
Compatible Bore Size [Max] (in)	5 in
Bore Size (in)	5 in
Total Length (in)	10.125 in
Length Through Bore (in)	10.125 in
Material	Ductile Iron or Gray Iron
Product Type	Split Taper Bushing
Cap Screws (Size)	5/8 x 2 3/4
Cap Screws (No.)	3
Bore Type	Inch

General Specifications

UPC	662289132874
Weight	30.25 LB
Packaged Length	18.90 IN
Packaged Width	13.60 IN
Packaged Height	14.00 IN
