• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bore Size (in)	5.5 in
Material	Ductile Iron or Gray Iron
Length Through Bore (in)	7.125 in
Cap Screws (Size)	5/8 x 2 3/4
Bushing Type	U1
Keyseat	1 1/4 x 5/8
Outside Diameter (in)	8.375 in
Model Name	U1_Type2_BushingMaster
Wrench Torque (in-lb)	1,680
Total Length (in)	7.125 in
Product Type	Split Taper Bushing
Compatible Bore Size [Max] (in)	5.5 in
Cap Screws (No.)	3
Bore Type	Inch
Screw Length	2.75
Flange Thickness	1.125
Barrel Diameter (Large End)	6
Includes	Set Screw, Cap Screws & Spcl Key
Thread Size	5/8-11
Flange Type	Split-Through Flange
Bolt Circle Diameter (in)	7
Mounting Type	Conventional
Barrel Diameter (Small End)	5.65

General Specifications

UPC	662289592692
Weight	17.55 LB
Packaged Length	12.10 IN
Packaged Width	10.60 IN
Packaged Height	10.10 IN
