• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Compatible Bore Size [Max] (in)	3.875 in
Cap Screws (Size)	5/8 x 2 3/4
Material	Ductile Iron or Gray Iron
Total Length (in)	7.125 in
Wrench Torque (in-lb)	1,680
Product Type	Split Taper Bushing
Bushing Type	U1
Keyseat	1 x 1/2
Length Through Bore (in)	7.125 in
Model Name	U1_Type1_BushingMaster
Outside Diameter (in)	8.375 in
Bore Size (in)	3.875 in
Bore Type	Inch
Cap Screws (No.)	3

General Specifications

UPC	662289272358
Weight	35.95 LB
Packaged Length	9.25 IN
Packaged Width	9.25 IN
Packaged Height	3.88 IN
