• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Outside Diameter (in)	8.375 in
Keyseat	1 x 1/2
Product Type	Split Taper Bushing
Wrench Torque (in-lb)	1,680
Compatible Bore Size [Max] (in)	4.4375 in
Cap Screws (Size)	5/8 x 2 3/4
Material	Ductile Iron or Gray Iron
Bore Size (in)	4.4375 in
Model Name	U0_Type2_BushingMaster
Length Through Bore (in)	4.9375 in
Bushing Type	U0
Total Length (in)	4.9375 in
Bore Type	Inch
Cap Screws (No.)	3

General Specifications

UPC	662289252060
Weight	23.29 LB
Packaged Length	12.10 IN
Packaged Width	10.60 IN
Packaged Height	10.40 IN
