• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bore Size (in)	3.1875 in
Wrench Torque (in-lb)	1,680
Cap Screws (Size)	5/8 x 2 3/4
Length Through Bore (in)	5.25 in
Material	Ductile Iron or Gray Iron
Model Name	U0_Type1_BushingMaster
Outside Diameter (in)	8.375 in
Total Length (in)	5.25 in
Bushing Type	U0
Keyseat	3/4 x 3/8
Compatible Bore Size [Max] (in)	3.1875 in
Product Type	Split Taper Bushing
Cap Screws (No.)	3
Bore Type	Inch

General Specifications

UPC	662289271900
Weight	33.80 LB
Packaged Length	8.50 IN
Packaged Width	8.50 IN
Packaged Height	5.25 IN
HTC	8483.90.8080
Country of Origin	Mexico
