• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Wrench Torque (in-lb)	1,680
Bushing Type	U0
Material	Ductile Iron or Gray Iron
Cap Screws (Size)	5/8 x 2 3/4
Product Type	Split Taper Bushing
Compatible Bore Size [Max] (in)	3.125 in
Outside Diameter (in)	8.375 in
Total Length (in)	5.25 in
Keyseat	3/4 x 3/8
Model Name	U0_Type1_BushingMaster
Length Through Bore (in)	5.25 in
Bore Size (in)	3.125 in
Cap Screws (No.)	3
Bore Type	Inch
Includes	Set Screw, Cap Screws and Ext. Key
Bolt Circle Diameter (in)	7
Screw Length	2.75
Mounting Type	Conventional
Barrel Diameter (Small End)	5.7656
Thread Size	5/8-11
Barrel Diameter (Large End)	6
Flange Thickness	0.75
Flange Type	Split-Through Flange

General Specifications

UPC	662289141975
Weight	30.36 LB
Packaged Length	8.50 IN
Packaged Width	8.50 IN
Packaged Height	5.25 IN
HTC	8483.90.8080
Country of Origin	Mexico
