• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Mounting Type	Conventional
Cap Screws (Bolt Circle)	3.3125
Cap Screws (No.)	3
Bushing Type	SK
Total Length (in)	1.75 in
Model Name	QD-SK_Bushing_Master
Torque Capacity (in-lb)	7,000
Outside Diameter (in)	3.875 in
Wrench Torque (ft.-lbs.)	15
Compatible Bore Size [Max] (in)	1.125 in
Product Type	Q-D Bushing
Cap Screws (Size)	5/16-18 x 2
Keyway	1/4 x 1/8
Bore Type	Inch
Length Through Bore (in)	1.75 in
Bore Size (in)	1.125 in
Barrel Length	1.1875 in
Flange Thickness	0.5625 in
Material	Ductile Iron - 65-45-37
Barrel Diameter	2.8125 in

General Specifications

UPC	662289395699
Weight	3.24 LB
Packaged Length	4.30 IN
Packaged Width	4.40 IN
Packaged Height	2.60 IN
