• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Torque Capacity (in-lb)	3,500
Length Through Bore (mm)	30.48 mm
Bore Type	Metric
Cap Screws (No.)	3
Bushing Type	SH
Wrench Torque (ft.-lbs.)	9
Mounting Type	Conventional
Cap Screws (Bolt Circle)	2.25
Compatible Bore Size [Max] (mm)	24 mm
Cap Screws (Size)	1/4-20 x 1 3/8
Keyway	8mm x 3.5mm
Product Type	Q-D Bushing
Model Name	QD-SH_Bushing_Master
Total Length (in)	1.2 in
Outside Diameter (mm)	68.2625 mm
Total Length (mm)	30.48 mm
Outside Diameter (in)	2.6875 in
Bore Size (mm)	24 mm
Barrel Diameter	1.871 in
Barrel Length	0.75 in
Flange Thickness	0.45 in
Material	Ductile Iron - 65-45-26

General Specifications

UPC	662289616275
Weight	1.44 LB
Packaged Length	3.90 IN
Packaged Width	3.70 IN
Packaged Height	1.50 IN
HTC	8483.90.8080
Country of Origin	Mexico
