• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Keyway	1/8 x 1/16
Torque Capacity (in-lb)	3,500
Wrench Torque (ft.-lbs.)	9
Total Length (in)	1.2 in
Model Name	QD-SH_Bushing_Master
Product Type	Q-D Bushing
Cap Screws (Size)	1/4-20 x 1 3/8
Compatible Bore Size [Max] (in)	0.5 in
Outside Diameter (in)	2.6875 in
Bore Type	Inch
Bushing Type	SH
Cap Screws (No.)	3
Length Through Bore (in)	1.2 in
Cap Screws (Bolt Circle)	2.25
Mounting Type	Conventional
Bore Size (in)	0.5 in
Barrel Length	0.75 in
Material	Ductile Iron - 65-45-13
Barrel Diameter	1.871 in
Flange Thickness	0.45 in

General Specifications

UPC	662289365449
Weight	1.19 LB
Packaged Length	3.90 IN
Packaged Width	3.70 IN
Packaged Height	1.50 IN
HTC	8483.90.8080
Country of Origin	Mexico
