• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Total Length (in)	1.995 in
Cap Screws (No.)	3
Outside Diameter (in)	4.625 in
Bore Type	Inch
Cap Screws (Bolt Circle)	3.875
Keyway	1/4 x 1/8
Compatible Bore Size [Max] (in)	1 in
Torque Capacity (in-lb)	11,000
Length Through Bore (in)	1.995 in
Bushing Type	SF
Product Type	Q-D Bushing
Model Name	QD-SF_Bushing_Master
Wrench Torque (ft.-lbs.)	30
Mounting Type	Conventional
Cap Screws (Size)	3/8-16 x 2
Bore Size (in)	1 in
Flange Thickness	0.5625 in
Barrel Diameter	3.125 in
Material	Gray Iron - G3000
Barrel Length	1.4375 in

General Specifications

UPC	662289355143
Weight	4.98 LB
Packaged Length	5.20 IN
Packaged Width	4.90 IN
Packaged Height	2.40 IN
