• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Length Through Bore (in)	1.995 in
Keyway	3/8 x 3/16
Cap Screws (Size)	3/8-16 x 2
Product Type	Q-D Bushing
Bore Type	Inch
Compatible Bore Size [Max] (in)	1.5625 in
Outside Diameter (in)	4.625 in
Bushing Type	SF
Total Length (in)	1.995 in
Mounting Type	Conventional
Wrench Torque (ft.-lbs.)	30
Cap Screws (No.)	3
Model Name	QD-SF_Bushing_Master
Cap Screws (Bolt Circle)	3.875
Torque Capacity (in-lb)	11,000
Bore Size (in)	1.5625 in
Material	Gray Iron - G3015
Flange Thickness	0.5625 in
Barrel Length	1.4375 in
Barrel Diameter	3.125 in

General Specifications

UPC	662289355211
Weight	4.36 LB
Packaged Length	5.00 IN
Packaged Width	5.20 IN
Packaged Height	2.40 IN
HTC	8483.90.8080
Country of Origin	Mexico
