• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Length Through Bore (in)	1.995 in
Total Length (in)	1.995 in
Cap Screws (No.)	3
Mounting Type	Conventional
Product Type	Q-D Bushing
Keyway	3/8 x 3/16
Wrench Torque (ft.-lbs.)	30
Outside Diameter (in)	4.625 in
Model Name	QD-SF_Bushing_Master
Bushing Type	SF
Bore Type	Inch
Compatible Bore Size [Max] (in)	1.5 in
Cap Screws (Bolt Circle)	3.875
Cap Screws (Size)	3/8-16 x 2
Torque Capacity (in-lb)	11,000
Bore Size (in)	1.5 in
Barrel Diameter	3.125 in
Flange Thickness	0.5625 in
Material	Gray Iron - G3001
Barrel Length	1.4375 in

General Specifications

UPC	662289405190
Weight	4.48 LB
Packaged Length	5.00 IN
Packaged Width	5.10 IN
Packaged Height	2.50 IN
