• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Product Type	Q-D Bushing
Outside Diameter (mm)	79.375 mm
Keyway	12mm x 4mm
Length Through Bore (mm)	33.782 mm
Cap Screws (Bolt Circle)	2.6875
Bore Type	Metric
Mounting Type	Conventional
Cap Screws (Size)	1/4-20 x 1 3/8
Bushing Type	SDS
Compatible Bore Size [Max] (mm)	40 mm
Wrench Torque (ft.-lbs.)	9
Total Length (mm)	33.782 mm
Torque Capacity (in-lb)	5,000
Cap Screws (No.)	3
Total Length (in)	1.33 in
Outside Diameter (in)	3.125 in
Bore Size (mm)	40 mm
Barrel Length	0.88 in
Material	Ductile Iron - 65-45-75
Barrel Diameter	2.1875 in
Flange Thickness	0.45 in

General Specifications

UPC	662289616039
Weight	1.15 LB
Packaged Length	4.60 IN
Packaged Width	4.70 IN
Packaged Height	1.70 IN
