• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bushing Type	SDS
Mounting Type	Conventional
Length Through Bore (in)	1.33 in
Cap Screws (No.)	3
Bore Type	Inch
Cap Screws (Size)	1/4-20 x 1 3/8
Cap Screws (Bolt Circle)	2.6875
Compatible Bore Size [Max] (in)	2 in
Total Length (in)	1.33 in
Wrench Torque (ft.-lbs.)	9
Torque Capacity (in-lb)	5,000
Outside Diameter (in)	3.125 in
Model Name	QD-SDS_Bushing_Master
Product Type	Q-D Bushing
Bore Size (in)	2 in
Barrel Length	0.88 in
Flange Thickness	0.45 in
Material	Ductile Iron - 65-45-66
Barrel Diameter	2.1875 in

General Specifications

UPC	662289355075
Weight	0.76 LB
Packaged Length	4.60 IN
Packaged Width	4.60 IN
Packaged Height	1.70 IN
