• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Model Name	QD-SDS_Bushing_Master
Mounting Type	Conventional
Torque Capacity (in-lb)	5,000
Cap Screws (Size)	1/4-20 x 1 3/8
Bore Type	Inch
Product Type	Q-D Bushing
Compatible Bore Size [Max] (in)	1.3125 in
Length Through Bore (in)	1.33 in
Total Length (in)	1.33 in
Cap Screws (No.)	3
Bushing Type	SDS
Wrench Torque (ft.-lbs.)	9
Cap Screws (Bolt Circle)	2.6875
Keyway	5/16 x 5/32
Outside Diameter (in)	3.125 in
Bore Size (in)	1.3125 in
Material	Ductile Iron - 65-45-58
Barrel Diameter	2.1875 in
Flange Thickness	0.45 in
Barrel Length	0.88 in

General Specifications

UPC	662289374946
Weight	1.76 LB
Packaged Length	4.80 IN
Packaged Width	4.50 IN
Packaged Height	1.60 IN
HTC	8483.90.8080
Country of Origin	Mexico
