• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Mounting Type	Conventional
Bushing Type	SD
Cap Screws (No.)	3
Wrench Torque (ft.-lbs.)	9
Compatible Bore Size [Max] (mm)	35 mm
Length Through Bore (mm)	46.482 mm
Torque Capacity (in-lb)	5,000
Product Type	Q-D Bushing
Outside Diameter (in)	3.125 in
Outside Diameter (mm)	79.375 mm
Total Length (in)	1.83 in
Bore Type	Metric
Total Length (mm)	46.482 mm
Keyway	10mm x 4mm
Cap Screws (Bolt Circle)	2.6875
Cap Screws (Size)	1/4-20 x 1 7/8
Bore Size (mm)	35 mm
Material	Ductile Iron - 65-45-39
Barrel Length	1.38 in
Flange Thickness	0.45 in
Barrel Diameter	2.1875 in

General Specifications

UPC	662289615858
Weight	1.55 LB
Packaged Length	4.20 IN
Packaged Width	4.20 IN
Packaged Height	2.00 IN
HTC	8483.90.8080
Country of Origin	Mexico
