• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Cap Screws (Size)	1/4-20 x 1 7/8
Bore Type	Inch
Keyway	3/8 x 3/16
Outside Diameter (in)	3.125 in
Cap Screws (No.)	3
Bushing Type	SD
Cap Screws (Bolt Circle)	2.6875
Model Name	QD-SD_Bushing_Master
Length Through Bore (in)	1.83 in
Product Type	Q-D Bushing
Compatible Bore Size [Max] (in)	1.375 in
Total Length (in)	1.83 in
Mounting Type	Conventional
Bore Size (in)	1.375 in
Wrench Torque (ft.-lbs.)	9
Torque Capacity (in-lb)	5,000
Material	Ductile Iron - 65-45-21
Barrel Length	1.38 in
Flange Thickness	0.45 in
Barrel Diameter	2.1875 in

General Specifications

UPC	662289364695
Weight	1.56 LB
Packaged Length	4.20 IN
Packaged Width	4.20 IN
Packaged Height	2.00 IN
HTC	8483.90.8080
Country of Origin	Mexico
