• Reverse mounting ability - This bushing system allows for mounting on either side of the product to allow for a more flush view of the product face.
• 3/4"/ft. Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Bushing Type	SD
Cap Screws (No.)	3
Total Length (in)	1.83 in
Outside Diameter (in)	3.125 in
Bore Type	Inch
Cap Screws (Bolt Circle)	2.6875
Mounting Type	Conventional
Torque Capacity (in-lb)	5,000
Wrench Torque (ft.-lbs.)	9
Length Through Bore (in)	1.83 in
Model Name	QD-SD_Bushing_Master
Product Type	Q-D Bushing
Cap Screws (Size)	1/4-20 x 1 7/8
Keyway	1/2 x 1/4
Compatible Bore Size [Max] (in)	1.9375 in
Bore Size (in)	1.9375 in
Material	Ductile Iron - 65-45-18
Flange Thickness	0.45 in
Barrel Diameter	2.1875 in
Barrel Length	1.38 in

General Specifications

UPC	662289364763
Weight	0.99 LB
Packaged Length	4.20 IN
Packaged Width	4.20 IN
Packaged Height	1.90 IN
