• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Keyseat	5/8 x 5/16
Material	Sintered Steel or Ductile Iron
Compatible Bore Size [Max] (in)	2.4375 in
Bore Size (in)	2.4375 in
Cap Screws (Size)	1/2 x 2 1/4
Bushing Type	S2
Model Name	S1-S2_Type1_BushingMaster
Product Type	Split Taper Bushing
Wrench Torque (in-lb)	840
Total Length (in)	6.75 in
Length Through Bore (in)	6.75 in
Outside Diameter (in)	6.375 in
Bore Type	Inch
Cap Screws (No.)	3

General Specifications

UPC	662289301591
Weight	22.30 LB
Packaged Length	6.50 IN
Packaged Width	6.75 IN
Packaged Height	6.50 IN
