• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Material	Sintered Steel or Ductile Iron
Wrench Torque (in-lb)	840
Bushing Type	S2
Total Length (in)	6.75 in
Compatible Bore Size [Max] (in)	2.375 in
Outside Diameter (in)	6.375 in
Length Through Bore (in)	6.75 in
Bore Size (in)	2.375 in
Cap Screws (Size)	1/2 x 2 1/4
Model Name	S1-S2_Type1_BushingMaster
Product Type	Split Taper Bushing
Keyseat	5/8 x 5/16
Cap Screws (No.)	3
Bore Type	Inch
Barrel Diameter (Large End)	4.625
Flange Thickness	0.75
Flange Type	Solid Flange
Barrel Diameter (Small End)	4.2696
Mounting Type	Conventional
Thread Size	1/2-13
Includes	Set Screw, Cap Screws and Ext. Key
Screw Length	2.25
Bolt Circle Diameter (in)	5.375

General Specifications

UPC	662289191567
Weight	22.78 LB
Packaged Length	7.50 IN
Packaged Width	7.00 IN
Packaged Height	7.00 IN
HTC	8483.90.8080
Country of Origin	Mexico
