• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Compatible Bore Size [Max] (in)	3.1875 in
Bore Size (in)	3.1875 in
Outside Diameter (in)	6.375 in
Model Name	S1-S2_Type1_BushingMaster
Keyseat	3/4 x 3/8
Material	Sintered Steel or Ductile Iron
Product Type	Split Taper Bushing
Cap Screws (Size)	1/2 x 2 1/4
Bushing Type	S1
Wrench Torque (in-lb)	840
Length Through Bore (in)	4.375 in
Total Length (in)	4.375 in
Cap Screws (No.)	3
Bore Type	Inch
Includes	Set Screw, Cap Screws and Ext. Key
Mounting Type	Conventional
Screw Length	2.25
Bolt Circle Diameter (in)	5.375
Thread Size	1/2-13
Flange Type	Solid Flange
Flange Thickness	0.75
Barrel Diameter (Small End)	4.418
Barrel Diameter (Large End)	4.625

General Specifications

UPC	662289191338
Weight	12.28 LB
Packaged Length	6.38 IN
Packaged Width	4.50 IN
Packaged Height	6.38 IN
