• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Cap Screws (Size)	1/2 x 2 1/4
Product Type	Split Taper Bushing
Length Through Bore (in)	4.375 in
Material	Sintered Steel or Ductile Iron
Bore Size (in)	1.6875 in
Wrench Torque (in-lb)	840
Outside Diameter (in)	6.375 in
Total Length (in)	4.375 in
Model Name	S1-S2_Type1_BushingMaster
Keyseat	3/8 x 3/16
Compatible Bore Size [Max] (in)	1.6875 in
Bushing Type	S1
Cap Screws (No.)	3
Bore Type	Inch

General Specifications

UPC	662289301133
Weight	20.78 LB
Packaged Length	6.50 IN
Packaged Width	4.50 IN
Packaged Height	6.63 IN
HTC	8483.90.8080
Country of Origin	Mexico
