• Lifetime Warranty - If this bushing ever fails Browning will replace it Free of charge.
• Solid Flange and Double Split Barrel - Assures better concentricity to the shaft.
• Key to Key Drive - With keys on both the shaft and product to provide the strongest possible drive.
• 3/4" per Foot Taper on Barrel - Self locking taper provides the highest degree of mechanical locking product to product.

Technical Specifications

Cap Screws (Size)	3/8 x 1 3/4
Length Through Bore (in)	4.875 in
Keyseat	7/8 x 7/16
Outside Diameter (in)	5.375 in
Total Length (in)	4.875 in
Bushing Type	R2
Material	Sintered Steel or Ductile Iron
Compatible Bore Size [Max] (in)	3.5 in
Wrench Torque (in-lb)	348
Bore Size (in)	3.5 in
Model Name	R1-R2_Type2_BushingMaster
Product Type	Split Taper Bushing
Cap Screws (No.)	3
Bore Type	Inch
Bolt Circle Diameter (in)	4.625
Flange Type	Solid Flange
Flange Thickness	0.625
Barrel Diameter (Large End)	4
Includes	Set Screw, Cap Screws and Ext. Key
Screw Length	1.75
Barrel Diameter (Small End)	3.75
Mounting Type	Conventional
Thread Size	3/8-16

General Specifications

UPC	662289261154
Weight	5.63 LB
Packaged Length	6.00 IN
Packaged Width	6.00 IN
Packaged Height	5.10 IN
